Marble Cutting Machine for Sale
Are you looking for a cost-effective stone processing machine? Our 3 axis bridge CNC saw cutting machine is favored by customers for its reasonable price and powerful cutting ability.
This marble cutting machine has accurate and durable Infrared sensor.and it adpots advanced servo motors dirve,which has higher precision, faster speed and lower noice.We can use the PLC control system to control the granite cutting tools,this controller is very easy to operate.The work table of this machine is a hydraulically working table,it can flip 85°,so we can Load and unload material more conveniently.The granite cutting tools machine can increase the work efficiency.It is a stone machine that you are worth investing in. It can almost meet all the needs of the stone market and can process almost all stone machines. If you are interested in this stone slab cutting machine,just contact us immediately.
Marble Cutting Machine Video
Feature of Marble Cutting Machine
Application In Widely Industries For Marble Cutting Machine
|Marble cutting machine Application Industry||Glass Industry|
|Stone monument Industry|
|Stone Decoration Industry|
|Stone Art Industry|
|Material that can be cut by Granite cutting tools||Stone||Marble|
CNC Saw Cutting machine Technical Parameters
|Descriptions||Granite Cutting Tools Parameters|
|MAX Saw Diameter/Max Cut Thick||400mm/70mm|
|Common Saw Diameter/Common Cut Thick||350mm/50mm|
|Cutting angle||90° or ±45°|
|Working table flip angle||85°|
|Working table flip method||Hydraulic|
|Main Power||11KW motor|
|X,Y,Z Traveling Accuracy||±0.025mm|
|Table Surface||Steel and hard PVC|
|Max. Rapid Travel Rate||25,000mm/min|
|Max. Working Speed||20,000mm/min|
|Drive Motors||Servo Motor|
|Gear reducer||Japan Shimpo|
|Working Voltage||380V 3 phase 50/60hz|
|Command Language||G Code|
|Running Environment||Temperature: 0℃~45℃ Relative Humidity: 30%~75%|
Main Parts of CNC Saw granite cutting tools
Steel Machine Frame
The CNC saw machine main frame is welded from thick square tubes. And it after heat treatment and vibration aging treatment, the machine can be used for a long time without deformation, maintain high cutting precision for a long time.
PLC Controller System
this controller has a easy interface.It supports import and work with DXF files and G codes automatically.and you can use it to do simple cuts in manual mode.
Cutting CNC Saw
The marble cutting machine is a bridge cutting saw machine,it has a CNC saw blade.The common used saw blade diameter is 350mm,and it can cut 50mm thickness material.And the max saw blade diameter is 400mm,which can cut 70mm thickness material.
Steel and hard PVC working table
The working table of CNC saw machine is made of steel pipe and hard PVC. The steel table is hard enough for bear heavy stone, and the PVC is easily to replace when it is damaged. And there are stainless steel water tray between the steel pipe and the PVC, which is for collecting the cooling water for cooling the saw.
hydraulic flip lift table
In order to make loading and unloading stone more convenient, our granite cutting tools installed a hydraulic flip lift table.Compared with the pneumatic lifting table, it is more reliable and powerful.
Enclosed dust-proof tank chain
This stone slab cutting machine adopts a closed dust-proof drag chain, and all wires are installed in the drag chain. The advantage of the closed drag chain is to isolate dust, water, oil, etc., to prevent damage to the wires and prolong the life of the machine.
Steel hollow platform
Material Leaning block
Add Your Heading Text Here
90°Vertical Cutting and Left&Right 45°Cutting
Oil Lubrication System
Projects of CNC Saw Marble Cutting machine
Strong Factory Strength
BuyCNC is with advanced and powerful machining capability. We have high precision 5 axis CNC Machining center to process the machine frame. The top milling, side milling, and side drilling will be finished in the same machining center by one clamping, which ensure our CNC stone machines are with higher precision. Not only the machine frames but also the small machining parts are machined by ATC CNC Center too.
High Precision Installation for Granite Stone Cutting Tools
During the installation of key components such as guide rails and racks, a dial indicator is used to check the installation accuracy to ensure the high precision of the stone slab cutting machine.
Packing for CNC Saw Machine
- Step 1: PVC film packing, which can ensure that the CNC granite cutting tools is completely covered, avoiding water and rust.
- Step 2: Wooden box packing, with a fixed template on the outermost layer.
- Step 3: All of the packing are inspected carefully by QC before delivery.
Pro-Sale Service of Marble Cutting machine
- Free sample testing service: you can send us the CAD file of the sample you want to cut, we will cut it at the factory and send the cutting video to you, or we can mail the sample to you.
- Personalized customized solutions: In order to meet your needs of cutting quality and efficiency, we can design unique solutions according to your requirements.
- Inquiries and consulting services for all granite cutting tools.
After-Sale Service of Stone Cutting machine
- The warranty period is 2 years for the CNC saw blade machine.
- When you need to replace the wearing parts of cheap CNC router, we will provide them at the agent price.
- If there are any problems during the warranty period, we will replace the main parts free of charge.
- The CNC Saw Cutter software provides free lifetime update service.
- 24-hour online technical support (phone, email, Teamviewer, Whatsapp, Skype, WeChat, QQ, etc.)
- We provide English training videos and user manuals for marble cutting machine installation and operation, etc. We can also provide technical guidance remotely.
- Free training at the BuyCNC factory.
- The engineer can repair the CNC granite cutting tools overseas.
Delivery for CNC Saw Blade machine
All of the CNC saw machine can be shipped worldwide. You can choose shipping by sea, by train, by truck, by air or by international express and DHL, FEDEX, UPS, etc. Click the button below to submit your information, we will provide you with professional service. Welcome!
