Vacuum Table 3 Axis CNC Router CNC Machine Wood Design Machine


This is the 2022 latest wood Router CNC machine, the 3 axis CNC router machine has dual-drive motors, more powerful power and faster processing speed. And this wood design machine uses an air-cooled spindle, which has a low failure rate and is more convenient to use. The worktable of this CNC cutter for wood is the Hybrid T-slot and Vacuum table, which is more convenient. Now This wood router CNC machine is on PROMOTION, if you want to know more information, please contact us.

Model                          ABS-1325-V-B

Rating                         ♥ ♥ ♥ ♥ ♥   4.8/5 based on 33 ratings and reviews

Spindle                      3kw water cooling or 3.5kw air cooling spindle

3 Axis Wood Router CNC Machine for Sale

This 3 axis wood router CNC machine has the solid welded steel tube machine mainframe and stable gantry. These materials have high rigidity and load-bearing strength, so you can process heavy workpieces with confidence. In terms of machine power, this 3 axis CNC router uses dual-drive motors, which are more powerful and run more stable. And this machine uses square rails, which have higher precision and longer service life. When there is a problem during processing, you can stop the machine process through the emergency stop button on the side of the machine to ensure that the production process is sufficiently safe. Of course, we also accept customization. If you are interested in this wood design machine, you are welcome to leave us a message, and we will reply you as quickly as possible.

Wood Router CNC Machine

Feature of 3 Axis CNC Router Machine

Double drive motor and high-power spindle

This router CNC machine is equipped with a dual-drive motor on the Y axis, which makes the machine more powerful, and The XY axis helical rack and pinion transmission, and Z-axis ball-screw transmission. The combination of these two transmission methods makes the machine run more stable, and the machining accuracy becomes higher. This 3 axis CNC router machine comes standard with a 3.5KW high-frequency air cooling spindle, and 4.5kw/6kw air cooling spindle on option. This kind of air cooling spindle is not prone to problems and has a long service life.

2. Hybrid work table and square rail

This wood design machine is equipped with an advanced multifunctional work surface. This worksurface combines a T-slot and a vacuum suction surface so that you can freely choose the way to fix the workpiece. This type of surface is very popular now. Moreover, the guide rails of this machine are square guide rails, which run smoother, hardly cause problems, and have a longer service life.

3. Comprehensive functions and good compatibility

The operation of This 3 Axis router CNC machine is very convenient. It has good compatibility and supports a variety of CNC software on the market, such as Vectric Aspire, Vectric Vcarve, Type3, Artcam, Castmate, Ucanam, JDpaint, and other CAD/CAM design software. You can use any kind of software you know how to control the machine. Not only that, but the CNC wood cutter also supports breakpoints, power-off memory functions, and can continue to work after being re-powered to improve work efficiency. The side of the machine is also equipped with an emergency stop button to ensure the safety of workers during work.

Application In Widely Industries For Affordable Wood Router CNC Machine

Navigation Bar

1) Furniture industry: Wood furniture, wooden door, windows, sofa, tables and chairs, cabinets and panels, 3D wave plate, computer desk, office furniture…

2) Advertising industry: Signage, billboard, logo, sign,3D characters cutting, acrylic letter cutting, LED/neon channel,literal-hole cut, lightbox, double-color plate engraving, and cutting…

3) Decoration industry: Screen partition, indoor wood decoration, living room background wall……

4) Musical instrument industry: Guitar, violin, cello, ukulele……

5) Crafts: Wine rack, clock, wood tray, decor risers, wood hanging planter, wood wall cross decor, DIY gift…

6) Plate processing industry: insulation part, plastic chemical components, PCB, inner body of the car, bowling tracks, stairs, anti-bate board, epoxy resin, ABS, PP, PE, and other carbon mixed compounds.

7) Others: voice box, game cabinets, computer tables, sewing machines table, insulation part, plastic chemical components, PCB, inner body of the car, bowling tracks, stairs, anti bate board, epoxy resin, ABS, PP, PE, and other carbon mixed compounds…….

3 Axis CNC Router Machine Technical Parameters

Navigation Bar
Descriptions 3 Axis CNC Router Parameters
Model ABS-1325-V-B
Working Area 1300*2500*200mm
Machine Frame Thick steel
Spindle Power 3.5kw air cooling spindle
Accuracy ±0.05mm
Table Surface Hybrid Vacuum &T-slot Table
X, Y Structure X Y axis helical gear transmission
Z Structure Z axis Taiwan TBI Ball Screw
Max. Rapid Travel Rate 25,000mm/min
Max. Working Speed 20,000mm/min
Spindle Speed 0-24,000RPM
Vacuum Pump 5.5kw
Drive Motors Stepper motor and driver
Working Voltage AC380V/3PH/50Hz
Command Language G Code
Operating System Mach 3(DSP Or NC-Studio)
Interface USB
Software capabilities Option: Vectric Aspire, Type3, Ucancam, Artcam, Solidworks, etc.
Running Environment Temperature: 0℃~45℃ Relative Humidity: 30%~75%

Main Parts of Wood Design Machine

Navigation Bar
3.5kw Air Cooling High Frequency spindle

High Frequency Air Cooling Spindle

1. This is the 3.5kw high-frequency air cooling coller spindle, this kind of spindle has high machining accuracy, fast machining speed, and can achieve a fully programmable speed from 6000 to 18000 RPM. Not only that, we also specially equipped it with a vacuum cover and wrench. If you want high power, we also have 4.5kw or 6kw high-frequency air-cooled spindles for your choice.

Mach 3 CNC Controller

This is the Mach 3 CNC Control system, it is also the most popular control system, it needs to be installed on a computer connected to the control machine, whether professionals or amateurs can quickly master it, so it is also the world The most common engraving machine control system on the Internet. You can use it to control the following types of machines: turning, milling, routers, laser and plasma plotter, engraving.

We use the Ethernet interface controller card, high reliability, anti-interference.

ABS-1325 CNC Router Mach3 controller
Hybrid Vacuum &T-slot Table

Hybrid Vacuum Work Table

This is the hybrid table surface, the 1-inch thick phenolic vacuum table surface mounted onto the steel base frame, keeping a rigid and consistent platform for your sheets and parts to be supported. And the vacuum table surface is multi-zoned which allows the operator to easily switch from full sheet processing to smaller part processing, (which requires a smaller segmented area), This worktable has 6 areas. In addition to vacuum suction to fix the workpiece, this wood router CNC machine is still working Multiple locations on the table surface include a heavy-duty aluminum T-slot profile. This T-slot can accommodate Alpha’s square M6 T-nuts. You can also use T-slots to fix the workpiece.

XY Axis Helical rack and pinion

The 3 Axis CNC Router uses precision helical gear racks on the X and Y axes. The mounting of the rack is inverted to help keep dust and debris from building up on the drive system, this assures smooth motion and long-term reliability. This The transmission method is not only safer, but also has a longer service life.

XY Axis High Quality Helical Rack Pinion of granite cutting tools
Drive Motors

Drive Motors

Z Axis TBI Ball screw

Z Axis TBI Ball screw

Omron Photoelectric limit switch

Omron Photoelectric limit switch

Fully enclosed drag chain

Fully enclosed drag chain

CNC Tool Calibration

CNC Tool Calibration

XY Z Axis Taiwan Square Rail

XY Z Axis Taiwan Square Rail

Neat and orderly electric control cabinet

Neat and orderly electric control cabinet

6 Vacuum Zones

6 Vacuum Zones

Heavy Welded Steel Pipes Gantry

Heavy Welded Steel Pipes Gantry

Optional Parts of CNC wood design Machine

Navigation Bar
Dust collector

Dust collector

Oil mist Coolant System

Oil mist Coolant System

Rotary Axis

Rotary Axis

Projects of Cheap Router CNC Machine

Navigation Bar
woodworking CNC sample3
woodworking CNC sample2

Strong Factory Strength

Navigation Bar
CNC Machining
Buycnc Machine Assembly Plant

BuyCNC is with advanced and powerful machining capability. We have high precision 5 axis CNC Machining center to process the machine frame. The top milling, side milling, and side drilling will be finished in the same machining center by one clamping, which ensure our CNC machines are with higher precision. Not only the machine frames but also the small machining parts are machined by ATC CNC Center too.

High Precision Installation for 3 axis router CNC machine

Navigation Bar

During the installation of key components such as guide rails and racks, a dial indicator is used to check the installation accuracy to ensure the high precision of the 3 axis CNC router machine.

Our Service

Navigation Bar

Packing for 3 axis CNC router

  • Step 1: PVC film packing, which can ensure that the  router CNC machine is completely covered, avoiding water and rust.
  • Step 2: Wooden box packing, with a fixed template on the outermost layer.
  • Step 3: All of the packing are inspected carefully by QC before delivery.
ABS-1325 CNC Router plywood case packing
ABS-1325 CNC Router Pro-Sale Service

Pro-Sale Service of CNC cutter For wood

  • Free sample testing service: you can send us the CAD file of the sample you want to cut, we will cut it at the factory and send the cutting video to you, or we can mail the sample to you.
  • Personalized customized solutions: In order to meet your needs of cutting quality and efficiency, we can design unique solutions according to your requirements.
  • Inquiries and consulting services for all 4×8 CNC router table cheap.

After-Sale Service of CNC cutter for wood

  • The warranty period is 2 years for the wood design machine.
  • When you need to replace the wearing parts of cheap CNC router, we will provide them at the agent price.
  • If there are any problems during the warranty period, we will replace the main parts free of charge.
  • The router CNC machine for sale software provides free lifetime update service.
  • 24-hour online technical support (phone, email, Teamviewer, Whatsapp, Skype, WeChat, QQ, etc.)
  • We provide English training videos and user manuals for 3 axis CNC router machine sale installation and operation, etc. We can also provide technical guidance remotely.
  • Free training at the BuyCNC factory.
  • The engineer can repair the CNC cutter for wood overseas.
ABS-1325 CNC Router After-Sales-Support
ABS-1325 CNC Router Support shipment Delivery

Delivery for 3 Axis CNC Router

All of the cheap CNC router can be shipped worldwide. You can choose shipping by sea, by train, by truck, by air or by international express and DHL, FEDEX, UPS, etc. Click the button below to submit your information, we will provide you with professional service. Welcome!

About BuyCNC

BuyCNC is a leading High-quality CNC Machine supplier in China. BuyCNC develops and sells various CNC machines including CNC Routers, Laser Machines, and Plasma Cutting Machines. Our main products are wood CNC router, stone CNC router, metal CNC router, ATC CNC router, 4 Axis CNC router, 5 Axis CNC router, CO2 laser  engraving cutting machine, fiber laser cutting machine, fiber laser marking machine, fiber laser welding machine, and metal plasma cutting machine etc.

The production complies with European standards and international quality control and has FDA, CE, SGS, and ISO9001 certification. The factory produces more than 1,000+ machines annually. And BuyCNC has Rich R & D’s experience which has been focusing on researching, developing, and manufacturing CNC machines for more than 20 years. Serving more than 150 countries and regions, we have 10000+ customers all over the world.

 You can get the wood router CNC machine directly without any CNC router distributor. Don’t hesitate anymore, tell us your needs to buy an cheap CNC router from BuyCNC.
