Laser Welder Machine Laser Beam Welding Handheld Laser Welding Machine

$5,880.00

This is a professional laser welder machine, which irradiates a high energy density laser beam on two parts of the material, melts the material, and then cools and solidifies into one. The weld seam of The laser beam welding machine is smooth and beautiful, no grinding is required. And the handheld laser welding is easy to operate, and it is a good choice for beginners to operate this machine through simple learning.

Fiber Laser Welder Video

laser welder
laser welder 2
laser welder 3
laser welder 4
laser welder 5
laser welder 6
laser welder 7
laser welder 8
laser welder9

Introduction of Laser Welder Machine

The laser welder machine uses high-energy laser pulses to locally heat the material in a small area. The energy of the laser radiation diffuses into the interior of the material through heat conduction, melting the material, and then cooling and solidifying into a whole.

The laser beam welding can perfectly control the laser without producing large welds and deformation. And the handheld laser welding machine can easily handle aluminum, brass and other materials with low consumption and support long-term welding.

Advantages of Handheld Fiber Laser Welder:

1. Laser beam welding machine can reduce the input heat to the minimum required amount, the metallographic change range of the heat affected zone is small, and the deformation caused by heat conduction is also the lowest.
2. Laser welder machine does not need to use electrodes, and there is no concern about electrode contamination or damage. And because it does not belong to the contact welding process, the wear and deformation of the equipment can be minimized.
3. The laser beam of handheld laser welding is easy to focus, align and be guided by optical instruments. It can be placed at an appropriate distance from the workpiece, and can be re-guided between tools or obstacles around the workpiece. Other welding methods are subject to the above space. restricted and unable to perform.
4. Laser welder machine’s laser beam can be focused on a small area, can weld small and closely spaced parts, can weld a wide range of materials, and can also bond various heterogeneous materials to each other.
5.Laser beam welding machine is not affected by the magnetic field (the arc welding and electron beam welding are easy), and can accurately align the weldment.
6. If handheld laser welding machine is welded by perforation, the depth-to-width ratio of the weld bead can reach 10:1.
7. When laser welder machine welding thin or thin wire, it will not have the trouble of melting back like arc welding.

Applications of Aluminum Laser Welding Machine:

laser welder machine is widely used in sheet metal processing, rail transit, automobiles, construction machinery, agricultural and forestry machinery, electrical manufacturing, elevator manufacturing, household appliances, food machinery, textile machinery, tool processing, petroleum machinery, food machinery, kitchenware and bathroom, decorative advertising, laser External processing services and other industries.

FAQ

1. How long is the warranty period of the Laser welder machine?
Our warranty period is 2 years. If there is any problem during the period, we will solve it as soon as possible after contacting us
2. How long is the cable?
Different generators have different lengths. The cable length of JPT is 7 meters, and the cable length of raycus and max is about 9 meters.
3. How thick can 1000w be welded
1000w laser welder machine can weld 2mm thick material
4. Is there a wire feeder?
We have three wire feeders to choose from, namely Hanwei, Qilin and Wanshunxing. If you are interested, you can contact us with your email address. We will send more detailed pictures to your email
5. Can aluminum be welded?
Yes, not only aluminum, all metal materials can be welded
6. Packaging
All our machines are packed in wooden cases
7. Language interface:
Chinese, English, Spanish and other languages ​​are optional, you can also set the language according to your needs

Our Service:

1. After sales

We provide 2 years warranty and lifetime maintenance for our products. During the warranty period, our product functional defects (except for man-made or force majeure factors) can be repaired or replaced free of charge (except vulnerable parts). After the warranty period, we only charge labor costs according to the actual situation.

2. Quality Control
In the production process of laser welder machine, BuyCNC has a skilled and strict quality inspection team. All finished machines we deliver are 100% rigorously tested by our QC department and engineering department. We will provide customers with detailed machine pictures and test videos before delivery.

3.7x24hours online service
If you have any questions to communicate with us, please contact us, we will reply you within 24 hours to solve the problem for you.
